15050 small axial fan

This series of fans consists of an aluminum alloy shell, asynchronous motor, single flange cylindrical shell, and fan blades. It has the characteristics of large air volume, low vibration, and low noise. The fan is mainly used for ventilation and heat dissipation in industries requiring large air volume, such as ground automatic control devices, large electronic equipment, cabinet, electric welding machine, and so on.

power：24W-29W
Air volume：280CFM-370CFM
Rotating speed：2450RPM-2650RPM

Please click the inquiry button below to contact us

Click here to inquire
Categories: , ,

Description

Specification:

This series of fans consists of aluminum alloy shell, asynchronous motor, single flange cylindrical shell and fan blades. It has the characteristics of large air volume, low vibration and low noise. The fan is mainly used for ventilation and heat dissipation in industries requiring large air volume, such as ground automatic control device, large electronic equipment, cabinet, electric welding machine and so on.

Technique parameters

Model Voltage Frequency Current Power Rotating speed Air Volume Wind Pressure Weight
HA15503BHL 380V 50Hz 0.22A 26W 2450RPM 280CFM 0.38Inch/H2O 0.95kg
HA15503BHL 380V 50Hz 0.22A 29W 2600RPM 340CFM 0.38Inch/H2O 0.95kg
HA15502SHL 230V 50Hz 0.22A 24W 2450RPM 280CFM 0.38Inch/H2O 0.95kg
HA15502BHL 230V 50Hz 0.22A 24W 2450RPM 280CFM 0.38Inch/H2O 0.95kg
HA15502BHL 230V 50Hz 0.22A 26.5W 2600RPM 340CFM 0.38Inch/H2O 0.95kg
HA15501BHL 115V 50Hz 0.22A 26W 2650RPM 320CFM 0.38Inch/H2O 0.95kg
HA15501BHL 115V 50Hz 0.22A 28W 2850RPM 370CFM 0.38Inch/H2O 0.95kg

Please fill out the form below and we will contact you as soon as possible.
