EC 35 series energy-saving fan

The EC35 series energy-saving fan is a low-power and high-efficiency permanent magnet brushless motor with a plastic casing, and the protection level is IP55. The motor has three installation methods, which are suitable for replacing the installation of various shaded pole motors.

Power：9W-37W
Air volume：
Rotating speed：1250r/min-1800r/min

Please click the inquiry button below to contact us

Click here to inquire
Categories: ,

Description

Specification:

The EC35 series energy-saving fan is a low-power and high-efficiency permanent magnet brushless motor with a plastic casing, and the protection level is IP55. The motor has three installation methods, which are suitable for replacing the installation of various shaded pole motors.

The main performance characteristics are:

(1) The motor is a three-winding permanent magnet brushless motor using fractional slot technology. It adopts vector control technology and has low vibration and noise, and its efficiency exceeds the energy efficiency requirements of various countries.

(2) The motor adopts low-noise ball bearings with reliable performance and long service life.

(3) The motor has over-voltage, over-current, and over-heat protection functions.

(4) The motor has the function of starting and blocking protection.

Technique parameters:



Model Voltage Frequency
(Hz)		 Curve
(NO.)		 Power
(W)		 Rotating speed
(r/min)		 Current
(A)		 Pressure
(Pa)		 Temperature
(ºC)
EC3502B-£-172/28* 230±10% 50/60 A 9 1800 0.08 28 -40- +50
EC3502B-£-200/28* 230±10% 50/60 B 9 1410 0.08 22 -40- +50
C 13 1800 0.11 25 -40- +50
EC3502B-£-200/31* 230±10% 50/60 D 11 1410 0.1 20 -40- +50
E 17 1800 0.14 29 -40- +50
EC3502B-£-200/34* 230±10% 50/60 F 11 1410 0.09 17 -40- +50
G 13 1800 0.13 25 -40- +50
EC3502B-£-230/28* 230±10% 50/60 H 17 1410 0.15 25 -40- +50
I 19 1550 0.15 34 -40- +50
EC3502B-£-230/31* 230±10% 50/60 J 23 1410 0.18 25 -40- +50
K 22 1550 0.18 30 -40- +50
EC3502B-£-230/34* 230±10% 50/60 L 25 1410 0.19 24 -40- +50
M 27 1550 0.21 35 -40- +50
EC3502B-£-254/25* 230±10% N 18 1410 0.16 25 -40- +50
P 17 1550 0.14 26 -40- +50
EC3502B-£-254/28* 230±10% Q 28 1360 0.21 27 -40- +50
R 28 1550 0.21 34 -40- +50
EC3502B-£-254/34* 230±10% S 28 1330 0.21 25 -40- +50
T 28 1550 0.21 28 -40- +50
EC3502B-£-300/22* 230±10% U 28 1300 0.21 19 -40- +50
V 37 1550 0.27 30 -40- +50
EC3502B-£-300/25* 230±10% W 29 1250 0.21 11 -40- +50
Z 36 1550 0.27 32 -40- +50
